What are the technical performance of diaphragm rupture alarm? The huaian diaphragm metering pump manufacturer coyu machinery to explain to you:
1, alarm way: the diaphragm rupture were soaked alarm or induction line, honking alarm immediately, at the same time, will relay contact by the off state into a closed state, switch output signal trigger or open other alarm device.
2. Probe: plate electrode type, water immersion detection height is greater than 0.5 mm.
3. Alarm host: when the detector is wet, the alarm will alarm and output the signal of the output switch.
4. Working voltage: AC220V.
5. Load capacity: no more than 10A.
6. Alarm volume: less than 100 db.
7. Other: power consumption is less than or equal to 0.1 watts, 125 x 100 x 50 mm.
8. Connect the diaphragm rupture alarm and the two leads of the sensor wire to the yellow and black lead wire of the host.
9. The two terminals on the left of the alarm host are connected to the 220V power supply, and the red light will be lighted when the work is done.
10. The two terminals on the right of the alarm host are connected to the relay contact, and the alarm will be changed into a closed state by the disconnection state, and the output switch volume signal will trigger or turn on other alarm devices. When the host alarm output is lit.
11. Turn the switch on the right side of the main engine to the "automatic" location for automatic monitoring, and when the "open" position can be manually called, stop the alarm when you dial the "off" position.
